String combiner box (SCB) PhoenixContact SOL-SC-1ST-0-DC-1MPPT-1101

RON 1,185.80 (VAT included)
Livrare gratuita
Financing through Online Credit smart by BT Direct
Calculate the rate
Installation
Product code - SKU 1056069
Available in 5-7 days from the order date
Add to Favorites
How can we help?
Call us: 0310.050.021 (Luni-Vineri 9 - 19)
Ask for details
Send us a message

Description

Electrical properties
MPP voltage A max. 1000 V DC
Current per string Imax max. 32 A
No-load voltage UOC max. 1100 V DC
Rated operating current DC-21B 32 A
Rated operating current DC-PV1 32 A
DC isolating switch
Overvoltage protection
EN type T1
IEC test classification T1
Protection level Up ≤ 3.5 kV
Total discharge current Itotal (10/350) µs 5 kA
Total discharge current Itotal (8/20) µs 40 kA
Rated short-circuit current ISCPV 32 A
DC input data
Number of inputs: strings 1 (per MPP tracker)
Number of MPP trackers supported 1

DC input
Input type SUNCLIX cable
Cable cross-section 2.5 mm² ... 6 mm²
Protective earth and protective earth conductor
Cable input type Preset
Connection method Screw connection
Cable cross-section 2x 16 mm²
Cable outer diameter 2x 6 mm ... 12 mm

DC output
Cable input type SUNCLIX
Cable cross-section 2.5 mm² ... 6 mm²
Dimensions
Width 180 mm
Height 180 mm
Depth 111 mm

Material specifications
Material Housing Polycarbonate
Material Cover/use Polycarbonate (transparent)
IP65 protection rating
Ambient temperature (operation) -20 °C ... 50 °C

Details

SKU
1056069
Categories
String Combiner BOX
Weight
3 kg
Brand
PHOENIX CONTACT
