Jinko Photovoltaic Panel 445W, JKMM445N-54HL4R-V, efficiency 22,27%

The Jinko JKM445N-54HL4R-V photovoltaic panel is a high-efficiency N-Type monocrystalline Tiger Neo series module with a rated power of 445W. Engineered for performance and durability, this single-faced panel takes advantage of the latest technologies to efficiently capture light and generate optimum energy efficiency.

Key features:

• High Efficiency: Up to 22.27% efficiency, making it one of the best performing panels in its range.
• Durable construction: Wind (4000 Pa) and snow (6000 Pa) resistant, suitable for extreme climatic conditions.
• SMBB (Multi-Busbar) technology: Improves current collection and increases long-term reliability.
• Anti-PID Performance: Reduces Potential Induced Degradation (PID) through an optimised manufacturing process.
• Hot 2.0 technology: Minimises initial degradation (LID/LETID) and ensures increased reliability.
• Positive Power Tolerance: 0~+3%, guaranteeing higher than rated actual efficiency.
• Resistance to external factors: Certified for protection against salt fog and ammonia, ideal for harsh environments.

Technical Specifications:

• Dimensions: 1762 × 1134 × 30 mm
• Weight: 22 kg
• Number of cells: 108 (2×54)
• Front glass: 3.2 mm with anti-reflection coating and high transmission.
• Frame: Anodised aluminium alloy.
• Junction box: IP68 (maximum protection against water and dust).
• Maximum system voltage: 1000/1500V DC (IEC).
• Operating temperature: -40°C to +85°C.
• Temperature coefficient Pmax: -0.29%/°C.
• Warranty: 15 years for product and 30 years for linear performance ( 0.40% annual degradation).

This Jinko 445W panel is an excellent choice for residential and commercial applications, offering an ideal combination of high efficiency, durability and a modern single-sided design. Certified to the most stringent international standards(IEC61215, IEC61730, ISO9001, ISO14001, ISO45001), this module guarantees stable energy production for decades.
